The S150HT stands out in the field of additive manufacturing with its ability to print using PEEK materials and other high-temperature substances. Characterized by its fine spot size and flexible forming space, it boasts a maximum operating temperature of up to 350℃ in the working chamber. This printer is specifically designed for tasks requiring high precision and endurance under extreme temperature conditions.
3D Printing TechnologySelective Laser Sintering (SLS)
Build Volume150×150×250mm
MaterialsCapable of printing with PEEK material
Parts Scanning SpeedUp to 13,000 mm/s
The S260 is a professional-grade additive manufacturing system, specifically designed with the education market in mind. It features a fine light spot and flexible building space, making it ideally suited for a variety of professional teaching and printing tasks. Its capabilities make it a valuable asset in educational settings, enabling hands-on learning and experimentation with additive manufacturing technologies.
3D Printing TechnologySelective Laser Sintering (SLS)
Build Volume260×260×450mm
SpecializationDesigned for easy operation in education
Parts Scanning SpeedUp to 8,000 mm/s
The S320HT is an additive manufacturing system, with the capability to print PEEK materials and other high-temperature substances. It stands out with its fine spot size, adaptable forming space, and notably high operating temperature, reaching up to 350℃ in the working chamber. This printer is particularly designed for applications requiring precision and endurance in extreme temperatures.
3D Printing TechnologySelective Laser Sintering (SLS)
Build Volume320×320×380mm
MaterialsCapable of printing with PEEK material
Parts Scanning SpeedUp to 13,000 mm/s.
The TPM3D S360 SLS printer is specifically designed for producing a wide range of products, including those for the aviation, locomotive, and household appliance sectors, as well as various plastic functional parts. This printer stands out for its high-efficiency additive manufacturing system, complemented by its superior overall performance.
3D Printing TechnologySelective Laser Sintering (SLS)
Build Volume360×360×600mm
Layer ThicknessVaries from 0.06 to 0.2 mm, with 0.12 mm (recommended)
Parts Scanning SpeedUp to 15,000 mm/s
The TPM3D S480 SLS Printer is designed for efficient production of plastic parts, suitable for both large batch manufacturing and smaller-volume production. This printer is recognized for its extensive molding range and high scanning speed. When combined with other models like the S260, it can manufacture both small and large parts, offering a balance between cost-effectiveness and high production capacity. This makes the S480 a preferred choice for additive manufacturing service providers.
3D Printing TechnologySelective Laser Sintering (SLS)
Build Volume480×480×600mm
Layer ThicknessVaries from 0.06 to 0.2 mm, with 0.12 mm (recommended)
Maximum Print SpeedUp to 21,000 mm/s.
The TPM3D S600DL is a Selective Laser Sintering (SLS) printer equipped with dual lasers and a digital dynamic focusing system. It's designed to enhance production efficiency while maintaining part quality. The printer has a notable build size of 600x600x800mm, which is currently among the largest in the SLS printer category. This capacity is significant for producing large-size parts.
3D Printing TechnologySelective Laser Sintering (SLS)
Build Volume600×600×800mm
Layer ThicknessVaries from 0.06 to 0.2 mm, with 0.12 mm (recommended)
Parts Scanning SpeedUp to 25,000 mm/s
