Laser Type
|
Fiber laser
|
|
Laser Wavelength
|
1064nm
|
|
Laser Power
|
2x 500W/3x 500W/4x 500W
|
|
Process
|
bi-directional scraper paving
|
|
Normal Build Style
|
0.05mm
|
|
Quick Build Style
|
0.05~0.15mm
|
|
Precision Build Style
|
0.02~0.05mm
|
|
Beam (diameter@1/e2)
|
0.06~0.20mm
|
|
Scanning Galvanometer
|
High Speed Scanning Galvanometer × 2
|
|
Parts Scanning Speed
|
up to 10.000mm/sec
|
|
Reference Building Speed
|
7.5~25cm³/h
|
|
Protective Gas
|
N2 / Ar (Active metal materials must be protected with Ar)
|
|
Flow Control
|
0~3 L/min intellient adjustment
|
|
Build Vat Volume
|
Approx. 80L
|
|
XY Platform
|
420mm(X) × 420mm(Y) (Screw hole, rounded, etc. are not calculated)
|
|
Z Axis
|
500mm (Z height includes thickness of build plate)
|
|
Max Weight
|
150kg
|
|
Build Vat Type
|
Precision resistor heater
|
|
Materials
|
Stainless Steel / Die Steel / Titanium Alloy / Aluminium Alloy / Co-Cr Alloy / Nickel Alloy / Cuprum etc.
|
|
Network
|
Ethernet, TCP/IP, IEEE802.3
|
|
Control Software
|
iSLM (Presto SLM)
|
|
Data Preparation Software
|
3dLayer
|
|
Data Interface
|
CLI file, SLC file, STL file
|
|
Power
|
380V(±10%) AC 50/60Hz, three-phase, 3/15A
|
|
Ambient Temperature
|
20-26ºC
|
|
Relative Humidity
|
Less than 40%, non-condensing
|
|
Installation Condition Size
|
2.65m(W)×1.45m(D)×2.70m(H)
|
|
Installation Condition Weight
|
Approx. 2800kg (Climbing platform not included)
|
|
Warranty
|
Laser: 5000 hours or 12 months (whichever comes first) Main Machine: 12 months from installation date
|
